This blog series explains how to engineer applications for DevOps.
Topics covered in this blog series include:
• Factors used to decide whether an application is a good candidate for DevOps.
• Practices to engineer designs for DevOps.
• DevOps applied to enterprise apps and software services.
• DevOps applied to COTS systems.
• DevOps applied to manufactured (embedded) systems software.
• Five levels of application maturity.
This blog covers five levels of application maturity. You can read part one here, part two here, part three here, part four here and part five here.
Five Levels of Application Maturity
Why is it that younger applications are more mature than older applications? DevOps works best with incremental changes rather than large complex changes that are time-consuming to change, build, test and deploy. DevOps also works best in ephemeral cloud computing infrastructures that can be scaled up and down quickly depending on short-term workload demands of supporting build, test and deployment requirements.
While existing applications will eventually be modernized to take advantage of the cloud, greenfield applications should be designed to exploit recent advancements in cloud-based platforms and application delivery.
The following paragraphs describe the characteristics of five levels of application maturity.
Spaghetti applications are older, monolithic legacy application designs that tend to be large and complex, like a big messy bowl of spaghetti. This complexity occurs partly because these older apps accumulate a massive amount of code and patches over time and partly because the architectural approaches at the time they were conceived did not have modular, cloud-oriented requirements in mind. Spaghetti applications are the least capable of taking advantage of cloud infrastructures.
Modular applications emphasize architecture designs that separate application components into functionally independent, interchangeable modules, such that each contains everything necessary to execute only one aspect of the desired functionality.
A module interface expresses the elements that are provided and required by the module. The elements defined in the interface are detectable by other modules. Modules often use a design style known as service-oriented architecture (SOA), where services are self-contained black boxes that provide capabilities to the other application modules, as a service, through a network protocol. SOA may be confused with microservices architecture.
There are key differences between SOA and microservices architecture that are important to DevOps. Microservices are preferred over SOA architecture because microservices are more fine-grained and restricted in what they can do. SOA uses an enterprise service bus for communication, whereas microservices use more lightweight stateless protocols and APIs managed as a product.
Changes to SOA modules usually require a new application release, while a change to a microservice usually only requires the microservice to be replaced. Migration of modular applications to the cloud may require rework to take advantage of cloud features such as autoscaling.
Cloud-ready applications that use the twelve-factor application modular design principles are more advanced. These modular designs emphasize declarative formats for automation, clean contracts with the underlying operating system and portability between execution environments. Deployment on modern cloud platforms obviates the need for servers and systems administration, minimizing divergence between development and production and enabling continuous deployment for maximum agility.
These characteristics and capabilities enable the application to scale up without significant changes to tooling, architecture or development practices. Cloud-ready applications can be easily mapped to virtual machines (VMs) available through cloud infrastructure services (IaaS) for VMs based on VMware vSphere or Microsoft Hyper-V.
Cloud-ready apps do not require rearchitecting or refactoring. They offer least-effort migration to the cloud with a lower availability rate. However, workloads such as legacy databases, third-party applications and homegrown business applications that are typically not designed for clustering or high availability suffer from a single point of failure.
Cloud-ready apps are expensive to maintain. This is primarily due to the way they consume computing, storage and network resources, even when idle. Each component of an app runs in a dedicated VM with no scope for optimization. Upgrading or patching results in downtime and makes maintenance complex and expensive. Ultimately, cloud-ready apps derive less value from the cloud than cloud-optimized or cloud-native applications.
Cloud-optimized applications take advantage of managed services offered by cloud providers. For example, instead of running a database in a VM, they consume database-as-a-service (DBaaS). Cloud-optimized apps typically target the platform-as-a-service (PaaS) delivery model of the cloud. They are portable and can be deployed in IaaS or PaaS. This reduces the deployment footprint, offering flexibility to IT teams. These apps are elastic, with the ability to easily scale in and scale out which results in optimal utilization of resources. Upgrading, patching and maintaining cloud-optimized apps is more manageable when compared to cloud-ready apps.
The downside of cloud-optimized apps is the learning curve involved in migrating to the cloud. Developers, operators and system administrators will have to learn new ways of deploying and managing workloads. Line-of-business applications with access to source code are great candidates for being cloud-optimized apps. They can be redesigned and rearchitected to take advantage of the cloud. Cloud-optimized apps can integrate and interoperate with cloud-ready applications.
Cloud-native applications are the most recent iteration of applications that are born in the cloud. They take full advantage of the cloud by exploiting capabilities such as elasticity, event-driven resource optimization and faster release cycles. Apps that are in the early stages of design and architecture are perfect candidates for cloud-native.
Cloud-native applications are designed as federated microservices, packaged and deployed as containers and managed through modern DevOps processes. When your organization needs to scale to thousands of services in the cloud, microservices application architectures offer major benefits over monolithic modular architectures, including the following:
• Separate microservices are better suited to different technology stacks.
• Federated microservices enable independent deployment of different parts of the system.
• Isolated deployments add to the resilience and fault-tolerance of the system.
• Scaling characteristics may be different for each microservice.
• APIs are used as connectors.
• Stateless protocols help assure seamless recovery.
• Event-driven programming reduces overhead and process latency.
• Antifragile practices inoculate against unanticipated failure modes.
The target deployment environment for cloud-native applications includes containers-as-a-service (CaaS) and functions-as-a-service (FaaS). This breed of apps delivers ultimate scalability and availability. Combined with continuous integration and continuous deployment, software is delivered rapidly, which accelerates time-to-market. It brings closed-loop feedback among developers, testers, operators and end users.
Cloud-native apps demand new skills of containerization, microservices and build and release management. However, the ROI is higher when compared to other app models. Greenfield applications that are still in the design phase are ideal for adopting the cloud-native pattern.
Diverse Applications for Cloud Migrations
Large enterprises moving to the cloud will deal with a diverse set of applications. Through hybrid connectivity and integration, spaghetti, modular, cloud-ready, cloud-optimized and cloud-native applications will co-exist and interoperate with each other. If you are after the benefits of modularity, make sure you do not trick yourself into a microservices-only mindset.
Explore the in-process modularity features or frameworks of your favorite technology stack. You will get support to enforce modular design instead of having to just rely on conventions to avoid spaghetti code. Then, make a deliberate choice whether you want to incur the complexity penalty of microservices. Sometimes you have no choice, but often, you can find a better way forward.
What This Means
This blog is one of a series that explained how to engineer applications to be most suitable for DevOps. Topics covered in this blog series include:
• Factors used to decide whether an application is a good candidate for DevOps.
• Practices to engineer designs for DevOps.
• DevOps applied to enterprise apps and software services.
• DevOps applied to COTS systems.
• DevOps applied to manufactured (embedded) systems software.
• Five levels of application maturity.
This blog covers five levels of application maturity. You can read part one here, part two here, part three here, part four here and part five here.
For more information regarding how to engineer applications for DevOps refer to my book Engineering DevOps.
